Description
FRAME HEIGHT
820mm, floor mounted type
WALL THICKNESS
minimum wall installation
thickness 110mm( thickness of cistern140mm)
DISCHARGE BEND SIZE
90mm
FLUSH
Flush adjsutable for 6/3L or 4.5/3L
CHARACTERISTIC
• Galvanised leg supports, adjustable from 0-120mm
• Water supply connection at the top,G 1/2″ BSP
• Activating panel available in various decorative finishing
• Powder – coated
• Heavy load for 400kg
WARRANTY
From Date of Purchase –
• Inwall Cistern : 5 Years
• Valves & Components : 1 Year
Proof of purchase is to be provided.
WARNING
All Gallaria inlet valves( concealed cistern & BTW suite) are warranted to perform under water pressure at up to 500Kpa. Anything above 500Kpa immediately voids warranty.
